MODEL C100
The FJORD AUDIO C100 is a reference preamplifier designed to maximize the purity of the audio signal through a tube-based pure balanced circuit and precise volume control. It delivers both delicate detail and natural musicality, unlocking the full potential of your entire system.
The FJORD AUDIO C100 is a reference tube preamplifier engineered to maximize the purity and expressiveness of music signals. A preamplifier is not just a device for switching inputs and adjusting volume—it is a critical component that determines the overall resolution and spatial presentation of a system.The C100 preserves the natural harmonics and musical texture unique to vacuum tubes while achieving the high transparency and resolution demanded by modern high-end audio.
KEY FEATURES
ENGINEERED TO PERFECTION
Pure Tube-Based Full Balanced Circuit
Zero Feedback Class A Amplification
UTS (Upper Tube Set) Design
64-Step Precision R2R Attenuator Volume
Separate Power Supply Design
Musicality of Tubes with Modern Resolution
Refined Design and Flexible Installation
Premium Dedicated Accessories
TECHNOLOGY
Pure Tube-Based Full Balanced Circuit
The C100 adopts a fully balanced circuit design, with the entire signal path from input to output driven by vacuum tubes without additional auxiliary circuits. The "Hot" and "Cold" signals are processed independently and remain completely separated throughout, greatly suppressing external interference, achieving extreme channel separation and a wide dynamic range, and enhancing the stereo field performance of music.
Zero Feedback Class A Amplification
The C100 features a coordinated architecture of Class A amplification and zero feedback circuit, abandoning the traditional feedback structure to improve the inherent integrity of the circuit. It not only retains the natural and smooth original texture of music signals but also achieves extremely high transparency, resolution and accurate musical expression; the pure Class A structure can stably amplify subtle signals, fully transmit musical details and energy, breaking through the resolution and transparency limitations of traditional tube preamplifiers.
UTS (Upper Tube Set) Design
Incorporates FJORD AUDIO's proprietary UTS technology, adopting inverted vacuum tube installation and a dedicated tube ring structure to suppress the tube microphonic effect and reduce external vibration interference; the vacuum tubes are closely combined and firmly fixed with a thick duralumin structure, further reducing noise and improving SNR performance.
64-Step Precision R2R Attenuator Volume
The volume control consists of a 64-step precision R2R attenuator volume controller, adopting a precise stepped structure to accurately maintain left-right channel balance and minimize signal transmission loss. Even in low-volume environments, it can fully retain musical details and spatial information, achieving precise volume adjustment and pure sound quality output.
Separate Power Supply Design
Adopts a separate layout of power supply and main unit, with fully independent power supply for left and right channels. Each channel is equipped with an independent toroidal transformer and dedicated power circuit, minimizing inter-channel interference and providing stable and reliable power supply; the power supply alone weighs 18 kg, which is a rare large-scale power design among preamplifiers.
Musicality of Tubes with Modern Resolution
The sound of the C100 combines the analog texture of vacuum tubes with outstanding resolution and a wide soundstage.It naturally reproduces the energy and detail of each instrument while effectively addressing the limitations in staging and transparency often found in traditional tube preamplifiers. The result is a more realistic and immersive spatial presentation.
